Yellow ploymide sheets mc nylon board casting nylon sheets Solid PA6 Blocks
Mc nylon means monomer casting nylon, is a kind of engineering plastics used in comprehensive industries, has been applied almost every industrial field.
Characteristics
-Excellent wear resistance
-Good sliding properties
-High strength and toughness
-Self-lubricating
-Resistant to oil, weak acid and alkali
-Shock absorption
-Noise absorption
-Good electrical properties
Technical Data Sheet
Images
Industry Applications
Gear/worm/cam
bearing
wheel/pulley/sheave/collar
sleeve/screws/nuts
washer/bushing
High pressure pipeline
storage containers
Oil Tank
Mc nylon means monomer casting nylon, is a kind of engineering plastics used in comprehensive industries, has been applied almost every industrial field.
Nylon Rods specifications
| Diameter (mm) | 40-500mm |
| Length (mm) | 500mm,1000mm, 2000mm |
Name: MC Nylon Polyamide
Colors include: Natural white, black, blue, green, yellow and other colors
Othe Types: rod,tubes,sheets&machine parts
Characteristics
-Excellent wear resistance
-Good sliding properties
-High strength and toughness
-Self-lubricating
-Resistant to oil, weak acid and alkali
-Shock absorption
-Noise absorption
-Good electrical properties
Technical Data Sheet
| PROPERTIES | Unit | Value |
| I.Physical Properties | ||
| Density | g/cm3 | 1.15~1.3 |
| Water absorption 24hrs | % | 2.5 |
| II.Thermal Properties | ||
| Heat deflection temperature - HDT/A | ºC | 95 |
| Min. service temperature | ºC | -30 |
| Max. service temperature | ºC | 105 |
| Thermal conductivity at 23 ºC | W/(K*m) | 0.23 |
| Coefficient of linear thermal expansion | 10-4*K-1 | 0.8 |
| Flammability Rating(6mm thickness) | - | HB |
| III.Mechanical Properties at 23ºC | ||
| Tensile strength at yield | MPa | 80 |
| Tensile strength at break | Mpa | - |
| Elongation at break | % | 3 |
| Modulus of elasticity after tensile test | MPa | 3,300 |
| Modulus of elasticity after flexural test | MPa | - |
| Hardness - Shore D | 84 | |
| Charpy impact strength | kJ/m2 | N. B. |
| Friction coefficient | 0.36 | |
| IV.Electrical Properties at 23ºC | ||
| Dielectric constant at 1 MHz | 106Hz | 3.70 |
| Dielectric loss factor at 1 MHz | 106Hz | 0.03 |
| Volume resistively | Ohm (Ω) * cm | ≥1015 |
| Surface resisively | Ohm (Ω) | ≥1013 |
| Dielectric strength | kV/mm | 50 |
| NOTE: 1 g/cm3 = 1,000 kg/m3, 1 Mpa = 1 N/mm2, 1kV/mm = 1 MV/m | ||
Images
Industry Applications
Gear/worm/cam
bearing
wheel/pulley/sheave/collar
sleeve/screws/nuts
washer/bushing
High pressure pipeline
storage containers
Oil Tank
