China product PP PE double stages plastic granulator factory automatic feed pellet making recycling machine
Usage:
This machine can process a variety of thermoplastic plastics,such as PC,PA,PP,ABS,PE,POM,PET etc. Different from LDC series, this kind of machine has two even three stages.
Features:
this machinery is used for PP PE ABS PA PS PET crushed material extruding and granule-making. It adopt the two-step structure to meet the the double-layer filter purpose. It can effectively remove the impurities from the recycling material and fully exhaust the gas.It can produce ample,consolidated and fine luster granules.
Material:
PP PE ABS PA PS
Model:
AP-SJP-130-120
Parameter trableAP
| Model | Screw dia. | Long dia. ratio | Out put(kg/h) | Screw rotate spoeed(r/min) | Power (KW) |
AP-SJP-100-90 | 100-90 | 28:1-10:1 | 120-150 | 73 | 30 |
AP-SJP-110-105 | 110-105 | 28:1-10:1 | 150-180 | 73 | 37 |
AP-SJP-120-115 | 120-115 | 28:1-10:1 | 200-220 | 73 | 45 |
AP-SJP-130-120 | 130-120 | 28:1-10:1 | 220-250 | 73 | 55 |
AP-SJP-140-130 | 140-130 | 28:1-10:1 | 250-300 | 73 | 75 |
AP-SJP-150-140 | 150-140 | 28:1-10:1 | 300-450 | 73 | 90 |
AP-SJP-125-115 HDPE | 125-115 | 28:1-10:1 | 200-220 | 73 | 45 |
AP-SJP-130-120 HDPE | 130-120 | 28:1-10:1 | 220-250 | 73 | 55 |
AP-SJP-140-130 HDPE | 140-130 | 28:1-10:1 | 250-300 | 73 | 75 |
AP-SJP-150-140 HDPE | 150-140 | 28:1-10:1 | 300-450 | 73 | 90 |
