Polyester braided twin
This product is made of 100% high - strength polyester fiber (polyester) fiber,and through two twisting, then the processing braided.
The rope is the most wear-resistant, weather-resistant, wear-resistant, anti-uv and chemical corrosion of all synthetic fibre ropes.
At the same time, the fracture strength and elongation are consistent with the standard state.
Suitable for high load continuous friction.
Application: cruise ship, mooring, towline, chemical boat, etc.
Details introduction
Density: 1.38 g/cm3(Not floating)
Melting point: 265 ° C
Elongation at break: 20 ~ 25%
Anti-UV: Excellent
Resistance to wear:Excellent
Chemical resistance:Very Good
8-strand Rope Parameter Table
12-strand Rope Parameter Table
Certificates
Packing
Workshop Picture
This product is made of 100% high - strength polyester fiber (polyester) fiber,and through two twisting, then the processing braided.
The rope is the most wear-resistant, weather-resistant, wear-resistant, anti-uv and chemical corrosion of all synthetic fibre ropes.
At the same time, the fracture strength and elongation are consistent with the standard state.
Suitable for high load continuous friction.
Application: cruise ship, mooring, towline, chemical boat, etc.
Details introduction
Density: 1.38 g/cm3(Not floating)
Melting point: 265 ° C
Elongation at break: 20 ~ 25%
Anti-UV: Excellent
Resistance to wear:Excellent
Chemical resistance:Very Good
8-strand Rope Parameter Table
| mm Dia | Circ | Weight | Breaking Strength | |||
| mm | Inch | Inch | KGS/100M | LBS/100FT | Ton | kN |
| 24 | 15/16 | 3 | 43.7 | 29.4 | 12.2 | 119.7 |
| 28 | 1-1/8 | 3-1/2 | 59.4 | 40.0 | 16.2 | 158.9 |
| 32 | 1-1/4 | 4 | 77.8 | 52.3 | 21.2 | 208.0 |
| 36 | 1-7/16 | 4-1/2 | 98.2 | 66.0 | 26.5 | 260.0 |
| 40 | 1-5/8 | 5 | 121.0 | 81.3 | 32.5 | 318.8 |
| 44 | 1-3/4 | 5-1/2 | 147.0 | 98.8 | 38.8 | 380.6 |
| 48 | 1-15/16 | 6 | 175.0 | 117.6 | 46.1 | 452.2 |
| 52 | 2-1/8 | 6-1/2 | 205.0 | 137.8 | 54.1 | 529.7 |
| 56 | 2-1/4 | 7 | 238.0 | 160.0 | 62.9 | 616.0 |
| 60 | 2-3/8 | 7-1/2 | 273.0 | 183.5 | 73.3 | 718.1 |
| 64 | 2-1/2 | 8 | 311.0 | 209.0 | 83.1 | 814.2 |
| 68 | 2-11/16 | 8-1/2 | 351.0 | 236.0 | 93.1 | 912.3 |
| 72 | 2-7/8 | 9 | 393.0 | 264.1 | 103.1 | 1010.4 |
| 80 | 3-1/4 | 10 | 485.0 | 327.0 | 127.1 | 1245.8 |
| 88 | 3-1/2 | 11 | 587.0 | 395.0 | 152.2 | 1491.1 |
| 90 | 3-9/16 | 11-1/4 | 614.0 | 413.0 | 158.2 | 1549.9 |
| 95 | 3-3/4 | 11-7/8 | 685.0 | 461.0 | 176.2 | 1726.5 |
| 96 | 3-3/4 | 12 | 699.0 | 470.0 | 181.2 | 1775.6 |
| 100 | 3-15/16 | 12-1/2 | 758.0 | 510.0 | 196.2 | 1922.7 |
| 104 | 4-1/8 | 13 | 820.0 | 551.1 | 209.2 | 2050.2 |
| 112 | 4-7/16 | 14 | 950.0 | 638.4 | 243.2 | 2383.8 |
| 120 | 4-3/4 | 15 | 1090.0 | 732.5 | 278.3 | 2727.1 |
12-strand Rope Parameter Table
| mm Dia | Circ | Weight | Breaking Strength | |||
| mm | Inch | Inch | KGS/100M | LBS/100FT | Ton | kN |
| 24 | 15/16 | 3 | 43.7 | 29.4 | 12.2 | 120.0 |
| 28 | 1-1/8 | 3-1/2 | 59.4 | 40.0 | 16.2 | 159.0 |
| 32 | 1-1/4 | 4 | 77.8 | 52.3 | 21.2 | 208.0 |
| 36 | 1-7/16 | 4-1/2 | 98.2 | 66.0 | 27.9 | 273.7 |
| 40 | 1-5/8 | 5 | 121.0 | 81.3 | 34.2 | 335.3 |
| 44 | 1-3/4 | 5-1/2 | 142.0 | 98.8 | 39.8 | 390.4 |
| 45 | 1-25/32 | 5-5/8 | 153.8 | 103.4 | 41.75 | 410.0 |
| 48 | 1-15/16 | 6 | 172.0 | 117.6 | 47.6 | 466.9 |
| 50 | 2 | 6-1/4 | 189.5 | 127.4 | 51.85 | 508.0 |
| 52 | 2-1/8 | 6-1/2 | 205.0 | 137.8 | 56.1 | 549.3 |
| 55 | 2-5/32 | 6-7/8 | 230.0 | 154.6 | 62.48 | 612.0 |
| 56 | 2-1/4 | 7 | 235.0 | 158.0 | 64.6 | 632.7 |
| 60 | 2-3/8 | 7-1/2 | 271.0 | 182.1 | 76.1 | 745.5 |
| 64 | 2-1/2 | 8 | 307.0 | 206.5 | 84.1 | 824.0 |
| 65 | 2-9/16 | 8-1/8 | 321.0 | 215.7 | 86.73 | 850.0 |
| 68 | 2-11/16 | 8-1/2 | 351.0 | 235.9 | 94.6 | 927.0 |
| 70 | 2-3/4 | 8-3/4 | 372.0 | 250.0 | 101.85 | 998.0 |
| 72 | 2-7/8 | 9 | 394.0 | 265.0 | 109.1 | 1069.3 |
| 75 | 3 | 9-3/8 | 427.0 | 287.0 | 118.1 | 1158.0 |
| 80 | 3-1/4 | 10 | 485.0 | 326.0 | 133.1 | 1304.7 |
| 85 | 3-3/8 | 10-5/8 | 548.0 | 368.3 | 149.42 | 1464.0 |
| 88 | 3-1/2 | 11 | 587.0 | 394.5 | 159.2 | 1559.7 |
| 90 | 3-9/16 | 11-1/4 | 615.0 | 513.4 | 167.2 | 1638.0 |
| 95 | 3-3/4 | 11-7/8 | 685.0 | 460.3 | 187.2 | 1834.0 |
| 96 | 3-3/4 | 12 | 700.0 | 470.4 | 191.2 | 1873.7 |
| 100 | 3-15/16 | 12-1/2 | 759.0 | 510.1 | 206.2 | 2021.0 |
| 104 | 4-1/8 | 13 | 821.0 | 551.7 | 221.2 | 2167.9 |
| 112 | 4-7/16 | 14 | 953.0 | 640.4 | 256.3 | 2511.3 |
| 120 | 4-3/4 | 15 | 1095.0 | 735.8 | 293.3 | 2874.2 |
