Product Show:
1.High rigidity heavy chassis, reducing the vibration generated during the high-speed cutting process.

2.Gantry double-drive structure,with imported Germany rack & gear transmission system, which improves the production efficiency.

3 High-performance cast aluminium guide rail, after infinite aalysis ,which accelerates the cicular arc cutting speed.

4.Open worktable, easy operation and small space occupation.

5. High precision, fast speed, narrow slit, minimum heat affected zone, smooth cut surface and no burr.

6. The laser cutting head does not come into contact with the surface of the material and does not scratch the workpiece.

7. The slit is the narrowest, the heat affected zone is the smallest, the local deformation of the workpiece is very small, and there is no mechanical deformation.

8.It has good processing flexibility, can process any pattern, and can cut pipes and other profiles.

9. Non-deformable cutting can be performed on materials of any hardness such as steel plates, stainless steel, aluminum alloy plates, and hard alloys.

Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet

Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet

Tube and rectangular tube can finish full automatic feeding without human operation. Deformed tubes can achieve artificial semi-automatic feeding. The fast corner response improves cutting efficiency greatly. The workpieces can be unloaded automatically in different areas after cutting.

LT Series is a milestone advancement in new fiber laser cutting technology. Specifically designed for high volume cutting of tubes and pipes the LT 9035 and LT 7535 provide far greater efficiency than normal laser systems when cutting pipes and tubular metals.
Tube and rectangular tube can finish full automatic feeding without human operation. Deformed tubes can achieve artificial semi-automatic feeding. The fast corner response improves cutting efficiency greatly. The workpieces can be unloaded automatically in different areas after cutting.

Farley Laserlabs new LT Series is a milestone advancement in new fiber laser cutting technology.
Specifically designed for high volume cutting of tubes and pipes the LT 9035 provides far greater efficiency than normal laser systems when cutting pipes and tubular metals.
New enhancements allow the LT9035 to position and move tubes and pipes mechanically (eliminating manual handling) to increase speed, precision and productivity.
Exclusive Functions of the 9035 Laser Pipe Cutting Machine
Full automatic Feeding system - regular and rectangular pipes can be integrated into a fully automated feeding process, without human operation.
Advanced clamping system can self adjust focus according to material size, automatically adjusting clamping force, this ensures that the correct amount of clamping force is applied so that pipes do not get damaged.
Corner fast cutting system provides fast response to corners, greatly improving cutting efficiency.
High efficiency unloading system - the LT9035 can be set to automatically unload finished work pieces, gently and safely in designated areasFarley Laserlabs new LT9035 is a milestone advancement in new fiber laser cutting technology.
Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet
Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet
Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet
Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet
ParameterLT9035LT7535
Processing Range20x10mm- 180x180mm20x10mm- 180x180mm
Standard MaterialCS, SS, ALU AlloyCS, SS, ALU Alloy
Cutting lengthMax. Length 7500mmMax. Length 8500mm
Automatic feeding Pipe length2000- 9000mm2000- 9000mm
Feeding stand bearing4000KG4000KG
CNC Axis No.1212
CNCSiemens 840DSiemens 840D
Laser Source1000-4000W1000-4000W

MaterialThicknessLaserPowerCutting Speed [m/min]Cutting GasGas Pressure [bar]
Mild Steel12000 W9,10O24
25,602,5
33,702,5
43,101,5
52,301,5
62,001,5
71,501,5
81,401,5
91,101,5
100,801,5
110,501,5
Stainless Steel14,60N210
22,8012
Company Introduction:
Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet


Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet

Wuhan Huagong Laser Engineering Co.,Ltd is one of the largest laser equipment manufacturers in China. HGLASER is the main subsidiary company of Huagongtech Co., Ltd. (Stock code: 000988)
Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet

HGLASER is a national key high-tech enterprise, possessing technology centers and provincial key laboratories. Relying on the National Engineering Research Center for Laser Processing, National Key Laboratory for Laser Technology and Exhibition Center for Laser Technology Processing, HGLASER undertakes national key projects and scientific research projects.
Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet
Super September Chinese Supplier Portable Laser Cutting Machine with Cast Bed for Plastic/Copper/Aluminum Sheet

Wuhan Huagong Laser Engineering Co.,Ltd possesses HGLASER and FARLEY?LASERLAB two famous brands. HGLASER has always been committed to providing broad and comprehensive laser manufacturing solutions in industrial manufacturing field, researching, manufacturing and selling various laser processing and plasma machining equipments, providing tube laser cutting processing and oil pipeline trade services. The main products of HGLASER cover the full power series of laser cutting systems, laser welding systems, laser marking series, laser texturing equipments, laser heat treatment systems, laser drilling machines, laser devices, all kinds of support devices, laser processing and plasma machining equipments, which are used widely in metallurgy, non-ferrous metals, automobiles, parts, aviation, military, precision instruments, machine manufacturing, hardware, integrated circuits, semiconductor manufacturing, solar, education, communication and measurement, packaging, leathers, plastics, rubbers, jewelries, crafts, medical equipments, etc.

FAQ

Q1 :How about warranty?

A1:3 years quality guaranty, the machine with main parts(excluding the consumables) shall be   changed free of charge(some parts will be maintained) when if any problem during the warranty period.

Q2:2 I don't know which one is suitable for me ?

A2:Please tell me your

1) Your materials

2) Max size of your material

3) Max cut thickness

4) Popular cut thickness

Q3:Do you have CE document and other documents for customs clearance?

A3:Yes,we have Original. At first we will show you and And after shipment we will give you      CE/Packing list/Commercial Invoice/Sales contract for customs clearance.

Q4:I don't know how to use after i receive Or i have problem during use,how to do?

A4:

1) We have detailed user manual with pictures and CD,you can learn step by step.And our user   manual update every month for your easy learning if there is any update on machine.

2) If have any problem during use,you need our technician to judge

The problem elsewhere will be solved by us. We can provide team viewer/Whatsapp/Email/Phone/Skype with cam till all of your problems finished.We can also provide Door service if you need.
