popular xinchai changchai quanchai Multi-Function hydraulic Drum Folder wheel loader
CS915 wheel loader is an efficient, elegant, secure and reliable mini engineering machine.
1. Hydraulic Torque Converter: There is little impact when engaging or shifting gears...
2. Luxurious Cab The seat could move forward, backward, upward and downward to adjust the space to increase driving comfort. The regulating knob on the left of the seat could adjust the seat elasticity according to driver's weight, therefore meeting ergonomic requirements. Seat belt, fire extinguisher, E4 approved glass and FOPS&ROPS cab guarantee more safety when emergency happens.
3. Optional equipments: Air conditioner, rearview camera, stereo equipment and so on
-----------------------------------------------------------------------------------------------------------------------------------------------
| Item | Specification | Item | Specification |
| Kerb weight | 3670kg | Max. speed | 20km/h |
| Rated bucket capacity | 0.65m³ | DRIVE AXLE | |
| Rated load | 1500kg | Main transmission type | Spiral gear, first stage deceleration |
| Max. tractive force | 25kN | TYRE | |
| Max. breakout force | 25kN | Type specification | 11.00-16 |
| Max. gradeability | 30% | Optional | 12.0-16.5; 14-17.5 |
| Max. dumping height | 2645mm | STEERING SYSTEM | |
| Dumping distance | 976mm | Type | Articulated load-sensing hydraulic steering system |
| Overall dimension(L*W*H) | 4709*1626*2645mm | Steering angle | 32° |
| ENGINE | Min. turning radius | 4283mm | |
| Model | A498BT1 | HYDRAULIC SYSTEM | |
| Type | Inline, direct injection, water cooling | System working pressure | 28MPa |
| Rated power | 36.8kW | Lifting time | 4.5s |
| Rated speed | 2400r/min | Total time | 10s |
| Optional | Cummins B3.3 | BRAKE SYSTEM | |
| Rated power | 45kW | Service brake | Air-over-hydraulic shoe-type |
| TRANSMISSION SYSTEM | Parking brake | Manual disc brake type | |
| Hydraulic torque converter | Single-stage three-element hydraulic torque converter | FILL CAPACITY | |
| Type of gear box | Axis-fixed, double reduction | Fuel | 51L |
| Gear shift | 2 forward shift, 2 reverse shift | Hydraulic oil | 68.6L |
Company:
Our company is the first factory which design the streamline outline mini loaders with CE in China, we name them as CS series.
Main products: CS906/910/912/915/918/920/936/956/966 series loaders, CSJ45/60/70/80/90/100 skid steer loader, CSRS60( rear wheel steer ) loader, Telescopic Loader and forklitfs.
Most of our wheel loaders are designed on the basis of European customers' suggestion. Now our products can be found working in more than 30 countries.
Product research and development is always one of the most important factors in our success, now we are specializing in producing and exporting of wheel loaders from 0.6 ton to 5 ton. CSREX has adopted ISO 9001: 2000, the international quality management system, and most of our products have also passed CE, SGS, TUV certificate.
We hope our professional experience and skills can bring you prosperity, and we look forward to establishing good, long-term business relationships with all of our customers.
We have designed first streamline small loader with middle hinge in China in July.2015. We export them to Europe , got many good feedbacks from customers.
Our factory is with baking finish house and biggest Electrophoresis line in Shandong ,wish your visiting to factory to check prouduction ability !
