20khz ultrasonic welding machine with touch screen for automobile welding
Brief Introduction:
Ultrasonic welding machine with modes of time model and engry model, it can automatically track and display real-time frequency, with amplitude stepping function, welding amplitude range up to 10-100(1%accuracy). There is also amplitude compensation; welding quality management (time,energy mutual detection), including clear traceable welding records (operation statistics) to control your welding quality in real time. It also features transducer overload protection, mold impedance analysis and protection to protect your equipment. Powerful, high quality and high welding stability.
We can develop kinds of automatic ultrasonic welding production line to meet customers' requirements.Standard ultrasonic welding
machine can be divided into table-type and cabinet-type. For cabinet-type,a delicate cabinet type work table in accordance
with ergonomics is arranged on the basis of the table-type ultrasonic plastic welder to facilitate operation.
Parameter:
| Frequency | Power | Working distance | Input voltage | Air pressure | System language |
| 15Khz | 2500W/3000W/4000W | 75mm/10mm | 220v or 110v | 0.2-0.8Mpa | English/Chinese |
| 20Khz | 2000W/3000W | 75mm | 220v or 110v | 0.2-0.8Mpa | English/Chinese |
| 30Khz | 1000W | 75mm | 220v or 110v | 0.2-0.8Mpa | English/Chinese |
| 35Khz | 1000W | 75mm | 220v or 110v | 0.2-0.8Mpa | English/Chinese |
| 40Khz | 800W | 75mm | 220v or 110v | 0.2-0.8Mpa | English/Chinese |
Application:
| Auto parts | bumpers, air filters, car audios, foot pads, door panels, clutch forks |
| Electric products | humidifiers, chargers, storage battery, telephones, sockets, flash discs |
| Medical products | leucocyte filters, accurate liquid medicine filters, blood plasma separating cups |
| Packaging and clothing | valve bags, paper cups, dairy food packing cases, bag belts, zippers |
| Stationery and toy | ink boxes, file folders, name card holders, albums |
Device Characteristics:
a. Suitable for welding pp, ps, pe, pc, abs, pbt, etc.;
b. No need any adhesives or flux, and less heat consumption;
c. Easy operation, high efficiency, excellent outward appearance, and high strength;
d. AIRTAC pneumatic components durability;
e. Automatic and manual operating mode, convenient for adjusting;
Advantages:
Real-time frequency automatic tracking
Welding mode: time, energy, ground
Amplitude step function
Welding amplitude 10%-100% adjustable (1% accuracy)
Amplitude compensation
Mold impedance analysis + protection
Overload protection
Voltage protection (input)
Transducer voltage protection
Quality management (time, energy mutual detection)
Welding record (running statistics)
Powerful, high quality, high welding stability, and other internal advantages cannot be enumerated.
