Our forged bevel gears are high quality and we also produce as per your sample or drawing
We produce special gear, sprocket, gear rack as per your sample or drawing and we also produce standard sprocket, gear, bevel gears, gear rack as follows:
1. Rang of product
03/04/05B/06B/08B/10B/12B/16B/20B/24B/28B/32B
25/35/40/41/50/60/80/100/120/140/160/180/200/240
2. Max. Processing diameter: ø =1450mm
The series of finished-bore sprocket
1. Rang of product
06B/08B/10B/12B/16B/20B/
35/40/41//50/60/80/100/120/140/160
2. Max. Processing diameter: ø =1450mm
Taper bore sprocket of BTL series
1. Rang of product
06B/08B/10B/12B/16B/20B
35/40/41//50/60/80/100/120/140/160
2. Max. Processing diameter: ø =1450mm.
Max. Coordinated taper bush: 8065
Taper bore sprocket of QTL series
1. Rang of product
35/40/41//50/60/80/100/120/140/160/200
2. Max. Processing diameter: ø =1450mm.
Max. Coordinated QD cover: N
STL taper bore sprocket
1. Rang of product
35/40/41//50/60/80/100/120/140/160/200
2. Max. Processing diameter: ø =1450mm.
Max. Coordinated Browning cover: U2
Molten sprocket wheel
1. Rang of product
06B/08B/10B/12B/16B/20B/24B(technological-bore & BTL taper bore)
We feel honoured to offer made to order product.
2. Max. Processing diameter: ø =1450mm. Max. Coordinated taper
Bush: 5050
3. Max. Weight of the casting 2000kg.
Coarse pitch conveyor sprocket
1. Rang of product
P50/P75/P100/P50.8
BTL taper bore sprocket of standard series
1. Rang of product
06B/08B/10B/12B/16B/20B
35/40/50/60/80/100/120/140/160
Flat-top conveyor sprockets
1. Rang of product
P 1/2"
Idle gear
1. Rang of product
06B/08B/10B/12B/16B
35/40/41/50/60/80
Worm wheels &Worms
1. Rang of product( Module M1M3, Pressure angle20°
2. Rang of product( diametral pitch 4DP16PD,
Pressure angle14.5°
Cylindrical spur gears
1. Rang of product( Module M1M6, Pressure angle20° Pierce
2. Rang of product( diametral pitch 4DP16PD, Pressure angle20° /14.5° . STL taper bore
Straight bevel gear
1. Rang of product( Module M1.5M5, Pressure angle20° Pierce
2. Rang of product( diametral pitch 4DP16PD, Pressure angle20° /14.5° STL taper bore
