Provide us with the detailed data according to the following drawing for us to quote.
| Diameter[D] | No. | Item Code | Groove[N] | Rope Diameter[d] | Groove distance [a] | Inner Diameter [E] | Pulley Width [B1] | Hub Width [B2] | Speed [m/s] |
| Φ320 | 1 | NE320001 | 4 | Φ8 | 12 | Φ80-Φ90 | 60 | 80 | ≤2 |
| 2 | NE320002 | Φ100-Φ110 | 85 | ≤2 | |||||
| 3 | NE320003 | Φ120-Φ130 | 90 | ≤2 | |||||
| 4 | NE320004 | 5 | Φ8 | 12 | Φ80-Φ90 | 72 | 80 | ≤2 | |
| 5 | NE320005 | Φ100-Φ110 | 85 | ≤2 | |||||
| 6 | NE320006 | Φ120-Φ130 | 90 | ≤2 | |||||
| 7 | NE320007 | 6 | Φ8 | 12 | Φ80-Φ90 | 85 | 80 | ≤2 | |
| 8 | NE320008 | Φ100-Φ110 | 85 | ≤2 | |||||
| 9 | NE320009 | Φ120-Φ130 | 90 | ≤2 | |||||
| Centrifugal polymerization one-piece metal bushing Nylon Pulley of same specification | ≤3 | ||||||||
| 1.Nier can supply standard parts such as Bearing, Shaft, U-bolt, etc according to customers' requirements. 2.Nier can produce other Non-standard elavator driving sheave according to customers' requirements. 3.The above are standard common parameters.Pulley with diameter of Φ320,Φ400,Φ520 and others can also be supplied. The below diameters of pulley are avaliable: Φ150/Φ200/Φ220/Φ240/Φ250/Φ260/Φ280 Φ290/Φ300/Φ330/Φ350/Φ360/Φ410/Φ420 Φ440/Φ450/Φ480/Φ500/Φ540/Φ600/Φ640 Scope of application: villa elevator, passenger elevator, cargo elevator, sightseeing elevator | |||||||||
| Diameter[D] | No. | Item Code | Groove[N] | Rope Diameter[d] | Groove distance [a] | Inner Diameter [E] | Pulley Width [B1] | Hub Width [B2] | Speed [m/s] |
| Φ400 | 1 | NE400001 | 4 | Φ10 | 14/15/16 | Φ100-Φ110 | 73 | 85 | ≤2 |
| 2 | NE400002 | Φ120-Φ130 | 90 | ≤2 | |||||
| 3 | NE400003 | Φ140 | 95 | ≤2 | |||||
| 4 | NE400004 | 5 | Φ10 | 14/15/16 | Φ100-Φ110 | 90 | 85 | ≤2 | |
| 5 | NE400005 | Φ120-Φ130 | 90 | ≤2 | |||||
| 6 | NE400006 | Φ140 | 95 | ≤2 | |||||
| 7 | NE400007 | 6 | Φ10 | 14/15/16 | Φ100-Φ110 | 105 | 85 | ≤2 | |
| 8 | NE400008 | Φ120-Φ130 | 90 | ≤2 | |||||
| 9 | NE400009 | Φ140 | 95 | ≤2 | |||||
| 10 | NE400010 | 7 | Φ10 | 14/15/16 | Φ140 | 120 | 95 | ≤2 | |
| 11 | NE400011 | Φ150-Φ160 | 115 | ≤2 | |||||
| 12 | NE400012 | 8 | Φ10 | 14/15/16 | Φ140 | 137 | 95 | ≤2 | |
| 13 | NE400013 | Φ150-Φ160 | 115 | ≤2 | |||||
| 14 | NE400014 | 9 | Φ10 | 14/15/16 | Φ140 | 153 | 115 | ≤2 | |
| 15 | NE400015 | Φ150-Φ160 | 115 | ≤2 | |||||
| Centrifugal polymerization one-piece metal bushing Nylon Pulley of same specification(No.1-9) | ≤3 | ||||||||
| Centrifugal polymerization one-piece metal bushing Nylon Pulley of same specification(No.10-15) | ≤4 | ||||||||
| 1.Nier can supply standard parts such as Bearing, Shaft, U-bolt, etc according to customers' requirements. 2.Nier can produce other Non-standard elavator driving sheave according to customers' requirements. 3.The above are standard common parameters.Pulley with diameter of Φ320,Φ400,Φ520 and others can also be supplied. The below diameters of pulley are avaliable: Φ150/Φ200/Φ220/Φ240/Φ250/Φ260/Φ280 Φ290/Φ300/Φ330/Φ350/Φ360/Φ410/Φ420 Φ440/Φ450/Φ480/Φ500/Φ540/Φ600/Φ640 Scope of application: villa elevator, passenger elevator, cargo elevator, sightseeing elevator | |||||||||
| Diameter[D] | No. | Item Code | Groove[N] | Rope Diameter[d] | Groove distance [a] | Inner Diameter [E] | Pulley Width [B1] | Hub Width [B2] | Speed [m/s] |
| Φ520 | 1 | NE500001 | 4 | Φ10 | 14/15/16 | Φ100-Φ110 | 73 | 85 | ≤2 |
| 2 | NE500002 | Φ120-Φ130 | 90 | ≤2 | |||||
| 3 | NE500003 | Φ140 | 95 | ≤2 | |||||
| 4 | NE500004 | 5 | Φ10 | 14/15/16 | Φ100-Φ110 | 90 | 85 | ≤2 | |
| 5 | NE500005 | Φ120-Φ130 | 90 | ≤2 | |||||
| 6 | NE500006 | Φ140 | 95 | ≤2 | |||||
| 7 | NE500007 | 6 | Φ10 | 14/15/16 | Φ100-Φ110 | 105 | 85 | ≤2 | |
| 8 | NE500008 | Φ120-Φ130 | 90 | ≤2 | |||||
| 9 | NE500009 | Φ140 | 95 | ≤2 | |||||
| 10 | NE500010 | 7 | Φ10 | 14/15/16 | Φ140 | 120 | 95 | ≤2 | |
| 11 | NE500011 | Φ150-Φ160 | 115 | ≤2 | |||||
| 12 | NE500012 | 8 | Φ10 | 14/15/16 | Φ140 | 137 | 95 | ≤2 | |
| 13 | NE500013 | Φ150-Φ160 | 115 | ≤2 | |||||
| 14 | NE500014 | 9 | Φ10 | 14/15/16 | Φ140 | 153 | 115 | ≤2 | |
| 15 | NE500015 | Φ150-Φ160 | 115 | ≤2 | |||||
| Centrifugal polymerization one-piece metal bushing Nylon Pulley of same specification(No.1-9) | ≤3 | ||||||||
| Centrifugal polymerization one-piece metal bushing Nylon Pulley of same specification(No.10-15) | ≤4 | ||||||||
| 1.Nier can supply standard parts such as Bearing, Shaft, U-bolt, etc according to customers' requirements. 2.Nier can produce other Non-standard elavator driving sheave according to customers' requirements. 3.The above are standard common parameters.Pulley with diameter of Φ320,Φ400,Φ520 and others can also be supplied. The below diameters of pulley are avaliable: Φ150/Φ200/Φ220/Φ240/Φ250/Φ260/Φ280 Φ290/Φ300/Φ330/Φ350/Φ360/Φ410/Φ420 Φ440/Φ450/Φ480/Φ500/Φ540/Φ600/Φ640 Scope of application: villa elevator, passenger elevator, cargo elevator, sightseeing elevator | |||||||||
FAQ
1. Are you manufacturer or trading company?
We are the leading manufacturer in Elevator Pulley field for more than 30 years, integrating R & D, Production and sales as one covering an area of 46,620 square meters.2. What material are you using for packing?
We can use cartons or wooden cases to pack the products according our customers' requirements.3. We methods are you using for shipping?
We can use Sea shipping, Air shipping and Express accordingly. We have long-term cooperation with TNT, FedEx, UPS, EMS and DHL, multiple ways to choose from.4. How can I place an order with you?
The best way is to send us your drawing and our engineer can make a drawing according to our exist mould. If you don't have a drawing, you can send us your data for the elevator or pulley, we can also make drawing accordingly.5. Do you have any other ways to introduce your company to all over the world?
We also attend exhibitions at home and abroad. Please leave us your contact information and we will send you invitation ahead of time.
